Using Autodesk Fusion with an Opus CNC Router
Bring design and manufacturing into one connected workflow. Autodesk Fusion can be used to create parts, develop CNC toolpaths, simulate machining and prepare controller-ready programmes for compatible Opus CNC routers.
From digital design to CNC machining
Autodesk Fusion, often still referred to as Fusion 360, combines design, manufacturing, simulation and project data tools in one platform. For CNC users, it provides a route from a 2D or 3D model through to toolpath creation and machine code.
It can be particularly useful for businesses producing engineered components, repeatable parametric designs, detailed 3D work or jobs that need more control over machining strategies. Design changes can remain connected to the manufacturing setup, helping reduce the need to rebuild a job from the beginning.
Fusion is a third-party software platform, so the exact tools available will depend on the Autodesk plan being used. Machine capability, tooling, workholding and the selected post processor must also be suitable for the intended operation.
Why businesses use Fusion for CNC routing
Fusion can support a more connected route from design to production, especially where parts are revised regularly or require more advanced machining preparation.
CAD and CAM together
Create or import a design, then move into manufacturing without relying on separate disconnected applications.
Parametric modelling
Build dimensions and relationships into a model so controlled changes can be made without redrawing the complete part.
Flexible toolpath creation
Prepare suitable machining strategies for profiling, pocketing, drilling, surface work and other supported CNC operations.
Simulation before machining
Review the planned tool movement before posting the programme, helping identify obvious setup or toolpath issues earlier.
Connected design revisions
When a model changes, associated manufacturing work can be reviewed and updated rather than recreated as a completely separate job.
Cloud-connected project data
Store and manage project information in a connected environment, with collaboration features available according to the selected plan.
A typical Fusion-to-CNC workflow
The exact process varies by machine, controller and job, but most CNC routing projects follow the same core stages.
Create or import the part
Build the design in Fusion or import compatible geometry from another design package.
Set up the job
Define the stock, machining orientation, work origin and the machine setup required.
Select tools and strategies
Choose appropriate cutters and generate toolpaths for the required machining operations.
Simulate and check
Review the tool movement, clearances and expected material removal before creating code.
Post and run safely
Use the correct post processor, transfer the programme and complete the machine-side checks.
Before machining, confirm the controller and post processor, work origin, tooling, feeds and speeds, safe heights, clamping, extraction and available machine travel. Complete an appropriate test or dry run before committing valuable material.
Fusion support from Opus CNC
Many Opus customers choose Fusion for more advanced CAD and CAM workflows. Members of our engineering team have completed Fusion training, helping us understand how the software connects with CNC machining and the machine controller.
- A compatible Opus post processor is available to registered customers through the Customer Portal.
- Our team can help confirm the correct machine and controller information for the intended workflow.
- Customers continue to receive technical support for their Opus CNC machine after installation and training.
What does the post processor do?
A post processor converts CAM toolpath data into the CNC code format required by a particular controller. The post must match the machine and controller configuration, so customers should use the version supplied or approved for their Opus machine.
Choose the correct Autodesk plan
Fusion features and usage rights vary between plans. Check Autodesk’s current terms before selecting a licence or building it into a production workflow.
Businesses using Fusion for paid or commercial work will normally require an appropriate commercial subscription.
Autodesk offers a limited personal-use version for qualifying non-commercial users. It is not intended for normal company or primary employment use.
Some advanced machining, simulation and manufacturing capabilities may require a different Fusion offering or additional functionality.
Software features, licensing and eligibility can change. Review the latest information directly on the Autodesk Fusion website.
Autodesk Fusion and Opus CNC FAQs
Practical answers to common questions from businesses considering Fusion for CNC routing.
Is Autodesk Fusion included with an Opus CNC router?
No. Opus 3-axis CNC routers are supplied with a lifetime licence of VCarve Pro. Fusion is an optional third-party platform that customers can obtain separately.
Can Fusion generate programmes for a CNC router?
Yes. Fusion can create CAM toolpaths and use a suitable post processor to convert them into the code format required by the CNC controller.
Where can Opus customers obtain the post processor?
Registered Opus customers can access the relevant Fusion post processor through the Opus CNC Customer Portal.
Will Fusion work with every Opus CNC machine?
Compatibility depends on the machine model, controller, number of axes and intended machining operation. Confirm the setup with Opus CNC before relying on it for production.
Is Fusion better than VCarve Pro?
They suit different workflows. VCarve Pro is straightforward and well suited to many everyday CNC routing jobs. Fusion provides broader CAD and CAM tools for users who need parametric design, detailed 3D modelling or more advanced manufacturing preparation.
Can a business use the free personal-use version?
The personal-use version is limited to qualifying non-commercial use and is not intended for normal company work. Businesses should check Autodesk’s current licensing terms and select an appropriate plan.
Planning a CNC workflow around Fusion?
Speak to the Opus CNC team about your materials, component sizes, required machining operations and production goals. We will help you identify the most suitable CNC router and controller setup.
