Oculus Free-Standing CO₂ Laser
Professional free-standing CO₂ laser cutting and engraving machinery for workshops, schools, makers, signage companies and production environments.
The Oculus Free-Standing laser range delivers accurate cutting and engraving across materials such as wood, acrylic, textiles, card, plastics and engraving laminates. It gives you more working area than a benchtop system while remaining practical, accessible and straightforward to operate.
Accurate Cutting and Engraving in a Practical Free-Standing Format
The Oculus Free-Standing CO₂ laser range is designed for users who need more capacity than a benchtop laser without stepping up to a full flatbed system. It is well suited to signage, education, creative production, acrylic fabrication, model making, personalisation and general workshop use.
With RDWorks control, air assist, motorised bed adjustment, CW chiller cooling and robust safety features, the Oculus Free-Standing range provides a dependable platform for day-to-day laser cutting and engraving.
Practical Features for Everyday CO₂ Laser Production
The Oculus Free-Standing range combines useful bed sizes, strong cutting performance and the essential features needed for accurate, repeatable laser work.
Designed for Precision, Speed and Versatility
From clean acrylic edges and engraved plaques to MDF, plywood, textiles, card and creative production work, the Oculus Free-Standing laser gives operators a practical way to cut and engrave a wide range of non-metal materials with confidence.
CO₂ Glass Tube
Power options across the range support detailed engraving, clean profiling and thicker non-metal cutting applications.
Robust Construction
The machine format is built for regular workshop use, helping support repeatable cutting and engraving results.
Fast Processing
Cutting speeds of up to 36,000mm/min and engraving speeds of up to 60,000mm/min support efficient production.
Automatic Bed Control
The motorised up/down bed helps with focusing and allows operators to work with different material heights.
RDWorks Software
RDWorks is supplied as standard, with LightBurn available as an upgrade for customers who prefer that workflow.
Safety Features
Enclosed cutting areas, emergency stops and safety cut-off features support safer operation in busy environments.
Oculus Free-Standing Laser Models
Choose the correct bed size and power configuration for your materials, access requirements and production needs.
Oculus 6090
Free-Standing CO₂ Laser- Working Area
- 600 x 900mm
- Dimensions
- 1070D x 1460W x 1300H
- CO₂ Power
- 100W
- Bed Type
- Honeycomb & blade
- Depth Allowance
- 400mm
- Voltage
- 240V
Oculus 1390
Free-Standing CO₂ Laser- Working Area
- 1300 x 900mm
- Dimensions
- 1370D x 1860W x 1300H
- CO₂ Power
- 130W / 150W upgrade
- Bed Type
- Honeycomb & blade
- Depth Allowance
- 400mm
- Voltage
- 240V
Oculus 1610
Free-Standing CO₂ Laser- Working Area
- 1600 x 1000mm
- Dimensions
- 1470D x 2160W x 1300H
- CO₂ Power
- 130W / 150W upgrade
- Bed Type
- Honeycomb & blade
- Depth Allowance
- 400mm
- Voltage
- 240V
Oculus 1812
Free-Standing CO₂ Laser- Working Area
- 1800 x 1200mm
- Dimensions
- 1670D x 2360W x 1300H
- CO₂ Power
- 130W / 150W upgrade
- Bed Type
- Honeycomb & blade
- Depth Allowance
- 400mm
- Voltage
- 240V
Oculus Free-Standing Technical Summary
The table below summarises the main features across the Oculus Free-Standing range. Final details can be confirmed by the Opus CNC team against your chosen model and configuration.
| Feature | Oculus Free-Standing Specification | Notes |
|---|---|---|
| Power Required | 240V household plug | No 3-phase supply required for the Oculus CO₂ laser range |
| Laser Source | CO₂ glass tube | Suited to non-metal cutting and engraving applications |
| Control System | RDWorks control system | LightBurn can be supplied as an upgrade |
| Cutting Speed | Up to 36,000mm/min | Dependent on material, thickness and settings |
| Engraving Speed | Up to 60,000mm/min | Dependent on material and engraving requirements |
| Bed and Depth | Honeycomb and blade table with 400mm depth allowance | Motorised up/down bed for easier focusing and material handling |
| Cooling and Extraction | CW chiller included with external hose extraction | Filtration can be discussed depending on your workshop setup |
| Also Included | Delivery, installation, training, RDWorks software and laser safety glasses | Training covers machine operation, software and safety |
| Warranty | 1 year parts and labour warranty | Consumables such as tubes, lenses and mirrors are excluded |
CO₂ lasers are designed primarily for non-metal materials. For sheet metal cutting, speak to Opus CNC about the Lumi ULTRA fibre laser range.
Oculus Free-Standing Samples and Applications
From signage and acrylic work through to wood, MDF, model making, textiles and detailed engraving, the Oculus Free-Standing range is designed for flexible CO₂ laser applications.
Request Oculus Free-Standing Laser Pricing
Tell us which bed size you are interested in and a member of the Opus CNC team will come back to you with the most suitable quotation.
Oculus Free-Standing Laser Quotation
Please complete the short form below and we will be in touch to discuss the correct machine size and configuration for your work.
Common Questions About the Oculus Free-Standing Laser
A practical overview of software, delivery, training, power requirements and bed sizes before choosing your Oculus laser.
Is Opus a UK company?
Yes. Opus CNC is based in Durham in the North East of England, with engineers supporting customers throughout the UK.
What software is supplied?
RDWorks is supplied with the Oculus laser range. LightBurn can also be supplied as an upgrade, which is useful for customers using Mac computers.
Is training included?
Yes. Machine and software training is included and covers machine operation, software use and safety, tailored to the operator’s experience level.
Is delivery included?
Yes. Delivery, installation and training are included. Larger models may require a suitable forklift for offloading depending on site access.
Do I need 3-phase power?
No. The Oculus Free-Standing laser range uses a 240V household plug supply and does not require 3-phase power.
What bed sizes are available?
The free-standing range includes 600 x 900mm, 1300 x 900mm, 1600 x 1000mm and 1800 x 1200mm models. Smaller models are available in the Oculus Benchtop range.
Spread the Cost of Your Oculus Free-Standing Laser
Opus CNC works with Anglo Scottish Asset Finance to help businesses explore competitive asset finance options for laser cutters, CNC routers and workshop machinery.
Asset Finance for Laser Machinery
Explore machinery finance options for the Oculus Free-Standing laser range with support from the Opus CNC team and Anglo Scottish Asset Finance.
Ready to Discuss the Right Oculus Free-Standing Laser for Your Business?
Speak with Opus CNC about bed size, power, materials, software, access requirements, delivery, installation, training and ongoing support.
